2023
Size chart and measurement information for this item
Board Size 150 154 156 158 162 154W 158W 162W 166W 170W
Weight Range 120-180 lbs. / 54-82kg 120-180 lbs. / 54-82kg 150-200 lbs. / 68-91kg 150-200 lbs. / 68-91kg 180-260 lbs.+ / 82-118kg+ 120-180 lbs. / 54-82kg 150-200 lbs. / 68-91kg 180-260 lbs.+ / 82-118kg+ 180-260 lbs.+ / 82-118kg+ 180-260 lbs.+ / 82-118kg+
Waist Width 248mm 250mm 252mm 254mm 256mm 258mm 262mm 264mm 266mm 270mm
Stance Location -12.5 -12.5 -12.5 -12.5 -12.5 -12.5 -12.5 -12.5 -12.5 -12.5
Binding Sizes M M/L M/L M/L L L L L L L
Running Length 1085mm 1125mm 1145mm 1165mm 1205mm 1125mm 1165mm 1205mm 1245mm 1285mm
Sidecut Radius 7.4m 7.6m 7.8m 7.9m 8.2m 7.6m 7.9m 8.2m 8.4m 8.7m
Sidecut Depth 20.0mm 20.8mm 21.1mm 21.5mm 22.2mm 20.8mm 21.5mm 22.2mm 23.0mm 23.7mm
Stance Width 505mm 530mm 530mm 560mm 560mm 530mm 560mm 560mm 560mm 560mm
Nose Width 288.1mm 291.5mm 294.3mm 297.0mm 300.5mm 299.5mm 305.0mm 308.5mm 312.0mm 317.4mm
Tail Width 288.1mm 291.5mm 294.3mm 297.0mm 300.5mm 299.5mm 305.0mm 308.5mm 312.0mm 317.4mm
Effective Edge 1135mm 1175mm 1195mm 1215mm 1255mm 1175mm 1215mm 1255mm 1295mm 1335mm
  2019

MEN'S BURTON CUSTOM SNOWBOARD

BOARD SIZE 150 154 156 158 162 154W 158W 162W 166W 170W
Weight Range 120-180 lbs. / 54-82 kg 120-180 lbs. / 54-82 kg 150-200 lbs. / 68-91 kg 150-200 lbs. / 68-91 kg 180-260 lbs.+ / 82-118 kg+ 120-180 lbs. / 54-82 kg 150-200 lbs. / 68-91 kg 180-260 lbs.+ / 82-118 kg+ 180-260 lbs.+ / 82-118 kg+ 180-260 lbs.+ / 82-118 kg+
Running Length 1085mm 1125mm 1145mm 1165mm 1205mm 1125mm 1165mm 1205mm 1245mm 1285mm
Waist Width 248mm 250mm 252mm 254mm 256mm 258mm 262mm 264mm 266mm 270mm
Sidecut Depth 20.0mm 20.8mm 21.1mm 21.5mm 22.2mm 20.8mm 21.5mm 22.2mm 23.0mm 23.7mm
Sidecut Radius 7.4m 7.6m 7.8m 7.9m 8.2m 7.6m 7.9m 8.2m 8.4m 8.7m
Stance Width 505mm 530mm 530mm 560mm 560mm 530mm 560mm 560mm 560mm 560mm
Nose Width 288.1mm 291.5mm 294.3mm 297.0mm 300.5mm 299.5mm 305.0mm 308.5mm 312.0mm 317.4mm
Tail Width 288.1mm 291.5mm 294.3mm 297.0mm 300.5mm 299.5mm 305.0mm 308.5mm 312.0mm 317.4mm
Effective Edge 1135mm 1175mm 1195mm 1215mm 1255mm 1175mm 1215mm 1255mm 1295mm 1335mm
Stance Location -12.5 -12.5 -12.5 -12.5 -12.5 -12.5 -12.5 -12.5 -12.5 -12.5
Binding Sizes M M M M M M M M M L
2018
BOARD SIZE 150 154 156 158 162 154W 158W 162W 166W 170W
Weight Range 120-180 lbs. / 54-82 kg 120-180 lbs. / 54-82 kg 150-200 lbs. / 68-91 kg 150-200 lbs. / 68-91 kg 180-260 lbs.+ / 82-118 kg+ 120-180 lbs. / 54-82 kg 150-200 lbs. / 68-91 kg 180-260 lbs.+ / 82-118 kg+ 180-260 lbs.+ / 82-118 kg+ 180-260 lbs.+ / 82-118 kg+
Running Length 1085mm 1125mm 1145mm 1165mm 1205mm 1125mm 1165mm 1205mm 1245mm 1285mm
Waist Width 248mm 250mm 252mm 254mm 256mm 258mm 262mm 264mm 266mm 270mm
Sidecut Depth 20.0mm 20.8mm 21.1mm 21.5mm 22.2mm 20.8mm 21.5mm 22.2mm 23.0mm 23.7mm
Sidecut Radius 7.4m 7.6m 7.8m 7.9m 8.2m 7.6m 7.9m 8.2m 8.4m 8.7m
Stance Width 505mm 530mm 530mm 560mm 560mm 530mm 560mm 560mm 560mm 560mm
Nose Width 288.1mm 291.5mm 294.3mm 297.0mm 300.5mm 299.5mm 305.0mm 308.5mm 312.0mm 317.4mm
Tail Width 288.1mm 291.5mm 294.3mm 297.0mm 300.5mm 299.5mm 305.0mm 308.5mm 312.0mm 317.4mm
Effective Edge 1135mm 1175mm 1195mm 1215mm 1255mm 1175mm 1215mm 1255mm 1295mm 1335mm
Stance Location -12.5 -12.5 -12.5 -12.5 -12.5 -12.5 -12.5 -12.5 -12.5 -12.5
Binding Sizes M M/L M/L M/L L L L L L L
  2017
BOARD SIZE 148 151 154 156 158 160 163 158W 162W 165W 169W
Weight Range 110-150 lbs. / 50-68 kg 125-165 lbs. / 57-75 kg 130-170 lbs. / 59-77 kg 135-175 lbs. / 61-79 kg 145-185 lbs. / 66-84 kg 155-195 lbs. / 70-88 kg 165-205 lbs. / 75-93 kg 145-185 lbs. / 66-84 kg 165-205 lbs. / 75-93 kg 170-210 lbs.+ / 77-95 kg+ 175-215 lbs.+ / 79-98 kg+
Running Length 1080mm 1110mm 1140mm 1160mm 1180mm 1200mm 1225mm 1180mm 1215mm 1240mm 1275mm
Waist Width 245mm 248mm 252mm 253mm 254mm 255mm 257mm 258mm 260mm 262mm 264mm
Sidecut Depth 20.0mm 20.5mm 21.0mm 21.4mm 21.8mm 22.2mm 22.6mm 21.8mm 22.4mm 22.8mm 23.5mm
Sidecut Radius 7.3m 7.5m 7.7m 7.9m 8.0m 8.1m 8.3m 8.0m 8.2m 8.4m 8.7m
Stance Width 505mm 530mm 530mm 530mm 560mm 560mm 560mm 560mm 560mm 560mm 560mm
Nose Width 284.9mm 289.0mm 294.1mm 295.8mm 297.5mm 299.3mm 302.2mm 301.5mm 304.8mm 307.7mm 311.0mm
Tail Width 284.9mm 289.0mm 294.1mm 295.8mm 297.5mm 299.3mm 302.2mm 301.5mm 304.8mm 307.7mm 311.0mm
Effective Edge 1122mm 1152mm 1182mm 1202mm 1222mm 1242mm 1267mm 1220mm 1255mm 1280mm 1315mm
Stance Location -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10
Binding Sizes S/M M M/L M/L M/L L L L L L L
  2016
Burton Custom Snowboard Burton Custom Snowboard Burton Custom Snowboard Burton Custom Snowboard Burton Custom Snowboard Burton Custom Snowboard Burton Custom Snowboard Burton Custom Snowboard Burton Custom Snowboard Burton Custom Snowboard Burton Custom Snowboard
BOARD SIZE 148cm 151cm 154cm 156cm 158cm 160cm 163cm 158Wcm 162Wcm 165Wcm 169Wcm
RUNNING LENGTH 1080mm 1110mm 1140mm 1160mm 1180mm 1200mm 1225mm 1180mm 1215mm 1240mm 1275mm
WAIST WIDTH 245mm 248mm 252mm 253mm 254mm 255mm 257mm 258mm 260mm 262mm 264mm
SIDECUT DEPTH 20.0mm 20.5mm 21.0mm 21.4mm 21.8mm 22.2mm 22.6mm 21.8mm 22.4mm 22.8mm 23.5mm
SIDECUT RADIUS 7.3m 7.5m 7.7m 7.9m 8.0m 8.1m 8.3m 8.0m 8.2m 8.4m 8.7m
STANCE WIDTH 505mm 530mm 530mm 530mm 560mm 560mm 560mm 560mm 560mm 560mm 560mm
NOSE WIDTH 284.9mm 289.0mm 294.1mm 295.8mm 297.5mm 299.3mm 302.2mm 301.5mm 304.8mm 307.7mm 311.0mm
TAIL WIDTH 284.9mm 289.0mm 294.1mm 295.8mm 297.5mm 299.3mm 302.2mm 301.5mm 304.8mm 307.7mm 311.0mm
EFFECTIVE EDGE 1122mm 1152mm 1182mm 1202mm 1222mm 1242mm 1267mm 1220mm 1255mm 1280mm 1315mm
STANCE LOCATION -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10
WEIGHT RANGE 110-150 lbs. / 50-68 kg 125-165 lbs. / 57-75 kg 130-170 lbs. / 59-77 kg 135-175 lbs. / 61-79 kg 145-185 lbs. / 66-84 kg 155-195 lbs. / 70-88 kg 165-205 lbs. / 75-93 kg 145-185 lbs. / 66-84 kg 165-205 lbs. / 75-93 kg 170-210 lbs.+ / 77-95 kg+ 175-215 lbs.+ / 79-98 kg+
BINDING SIZES Small/Medium Medium Medium/Large Medium/Large Medium/Large Large Large Large Large Large Large
  2015 Burton Custom CUSTOM SIZE CHART
Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard
BOARD SIZE 148cm 151cm 154cm 156cm 158cm 160cm 163cm 158Wcm 162Wcm 165Wcm 169Wcm
RUNNING LENGTH 1080mm 1110mm 1140mm 1160mm 1180mm 1200mm 1225mm 1180mm 1215mm 1240mm 1275mm
WAIST WIDTH 245mm 248mm 252mm 253mm 254mm 255mm 257mm 258mm 260mm 262mm 264mm
SIDECUT DEPTH 20.0mm 20.5mm 21.0mm 21.4mm 21.8mm 22.2mm 22.6mm 21.8mm 22.4mm 22.8mm 23.5mm
SIDECUT RADIUS 7.3m 7.5m 7.7m 7.9m 8.0m 8.1m 8.3m 8.0m 8.2m 8.4m 8.7m
STANCE WIDTH 505mm 530mm 530mm 530mm 560mm 560mm 560mm 560mm 560mm 560mm 560mm
NOSE WIDTH 284.9mm 289.0mm 294.1mm 295.8mm 297.5mm 299.3mm 302.2mm 301.5mm 304.8mm 307.7mm 311.0mm
TAIL WIDTH 284.9mm 289.0mm 294.1mm 295.8mm 297.5mm 299.3mm 302.2mm 301.5mm 304.8mm 307.7mm 311.0mm
EFFECTIVE EDGE 1122.5mm 1152.5mm 1182.5mm 1202.5mm 1222.5mm 1242.5mm 1267.5mm 1220mm 1255mm 1280mm 1315mm
STANCE LOCATION -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10
WEIGHT RANGE 110-150 lbs. / 50-68 kg. 125-165 lbs. / 57-75 kg. 130-170 lbs. / 59-77 kg. 135-175 lbs. / 61-79 kg. 145-185 lbs. / 66-84 kg. 155-195 lbs. / 70-88 kg. 165-205 lbs. / 75-93 kg. 145-185 lbs. / 66-84 kg. 165-205 lbs. / 75-93 kg. 170-210 lbs.+ / 77-95 kg.+ 175-215 lbs.+ / 79-98 kg.+
BINDING SIZES Small/Medium Medium Medium/Large Medium/Large Medium/Large Large Large Large Large Large Large
    2014 Burton Custom�
Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard
BOARD SIZE 148cm 151cm 154cm 156cm 158cm 160cm 163cm 158Wcm 162Wcm 165Wcm 169Wcm
RUNNING LENGTH 1080mm 1110mm 1140mm 1160mm 1180mm 1200mm 1225mm 1180mm 1215mm 1240mm 1275mm
WAIST WIDTH 245mm 248mm 252mm 253mm 254mm 255mm 257mm 258mm 260mm 262mm 264mm
SIDECUT DEPTH 20mm 20.5mm 21.1mm 21.4mm 21.8mm 22.2mm 22.6mm 21.8mm 22.4mm 22.9mm 23.5mm
SIDECUT RADIUS 7.32m 7.52m 7.73m 7.87m 8.01m 8.14m 8.31m 8.01m 8.25m 8.42m 8.66m
STANCE WIDTH 505mm 530mm 530mm 530mm 560mm 560mm 560mm 560mm 560mm 560mm 560mm
NOSE WIDTH 284.9mm 289mm 294.1mm 295.8mm 297.5mm 299.3mm 302.2mm 301.5mm 304.8mm 307.7mm 311mm
TAIL WIDTH 284.9mm 289.0mm 294.1mm 295.8mm 297.5mm 299.3mm 302.2mm 301.5mm 304.8mm 307.7mm 311mm
EFFECTIVE EDGE 1123mm 1153mm 1183mm 1203mm 1223mm 1243mm 1267.5mm 1220mm 1255mm 1280mm 1315mm
STANCE LOCATION 10 10 10 10 10 10 10 10 10 10 10
WEIGHT RANGE 110-150 lbs. / 50-68 kg. 125-165 lbs. / 57-75 kg. 130-170 lbs. / 59-77 kg. 135-175 lbs. / 61-79 kg. 145-185 lbs. / 66-84 kg. 155-195 lbs. / 70-88 kg. 165-205 lbs. / 75-93 kg. 145-185 lbs. / 66-84 kg. 165-205 lbs. / 75-93 kg. 170-210 lbs.+ / 77-95 kg.+ 175-215 lbs.+ / 79-98 kg.+
BINDING SIZES Small/Medium Medium Medium/Large Medium/Large Medium/Large Large Large Large Large Large Large
  2014 Burton Custom Restricted
Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard
BOARD SIZE 151cm 154cm 156cm 158cm 160cm
RUNNING LENGTH 1100mm 1130mm 1150mm 1160mm 1180mm
WAIST WIDTH 246mm 248mm 249mm 250mm 251mm
SIDECUT DEPTH 20.3mm 20.9mm 21.2mm 21.4mm 21.8mm
SIDECUT RADIUS 7.46m 7.66m 7.80m 7.86m 8.00m
STANCE WIDTH 530mm 560mm 560mm 560mm 560mm
NOSE WIDTH 286.6mm 289.7mm 291.5mm 292.8mm 294.6mm
TAIL�WIDTH 286.6mm 289.7mm 291.5mm 292.8mm 294.6mm
EFFECTIVE EDGE 1145mm 1175mm 1195mm 1205mm 1225mm
STANCE LOCATION 0 0 0 0 0
WEIGHT RANGE 125-165 lbs. / 57-75 kg. 130-170 lbs. / 59-77 kg. 135-175 lbs. / 61-79 kg. 145-185 lbs. / 66-84 kg. 155-195 lbs. / 70-88 kg.
BINDING SIZES Small/Medium Medium Medium/Large Medium/Large Medium/Large
  2013 Custom Specs
Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard
BOARD SIZE 151cm 154cm 156cm 158cm 160cm 163cm 158Wcm 162Wcm 165Wcm 169Wcm
RUNNING LENGTH 1110mm 1140mm 1160mm 1180mm 1200mm 1225mm 1180mm 1215mm 1240mm 1275mm
WAIST WIDTH 248mm 252mm 253mm 254mm 255mm 257mm 258mm 260mm 262mm 264mm
SIDECUT DEPTH 20.5mm 21.05mm 21.4mm 21.75mm 22.15mm 22.6mm 21.75mm 22.4mm 22.85mm 23.5mm
SIDECUT RADIUS 7.52m 7.73m 7.87m 8.01m 8.14m 8.31m 8.01m 8.25m 8.42m 8.66m
STANCE WIDTH 530mm 530mm 530mm 560mm 560mm 560mm 560mm 560mm 560mm 560mm
NOSE WIDTH 289mm 294.1mm 295.8mm 297.5mm 299.3mm 302.2mm 301.5mm 304.8mm 307.7mm 311mm
TAIL WIDTH 289mm 294.1mm 295.8mm 297.5mm 299.3mm 302.2mm 301.5mm 304.8mm 307.7mm 311mm
EFFECTIVE EDGE 1152.5mm 1182.5mm 1202.5mm 1222.5mm 1242.5mm 1267.5mm 1220mm 1255mm 1280mm 1315mm
STANCE LOCATION 10 10 10 10 10 10 10 10 10 10
WEIGHT RANGE 125-165 lbs. / 57-75 kg. 130-170 lbs. / 59-77 kg. 135-175 lbs. / 61-79 kg. 145-185 lbs. / 66-84 kg. 155-195 lbs. / 70-88 kg. 165-205 lbs. / 75-93 kg. 145-185 lbs. / 66-84 kg. 165-205 lbs. / 75-93 kg. 170-210 lbs.+ / 77-95 kg.+ 175-215 lbs.+ / 79-98 kg.+
BINDING SIZES Medium Medium/Large Medium/Large Medium/Large Large Large Large Large Large Large

Burton Custom Snowboard Specs 2012

Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard
BOARD SIZE 151cm 154cm 156cm 158cm 160cm 163cm 158Wcm 162Wcm 165Wcm 169cm
RUNNING LENGTH 1110mm 1140mm 1160mm 1180mm 1200mm 1225mm 1180mm 1215mm 1240mm 1275mm
WAIST WIDTH 248mm 252mm 253mm 254mm 255mm 257mm 258mm 260mm 262mm 264mm
SIDECUT DEPTH 20.5mm 21.05mm 21.4mm 21.75mm 22.15mm 22.6mm 21.75mm 22.4mm 22.85mm 23.5mm
SIDECUT RADIUS 7.52m 7.73m 7.87m 8.01m 8.14m 8.31m 8.01m 8.25m 8.42m 8.66m
STANCE WIDTH 530mm 530mm 530mm 560mm 560mm 560mm 560mm 560mm 560mm 560mm
NOSE WIDTH 289mm 294.1mm 295.8mm 297.5mm 299.3mm 302.2mm 301.5mm 304.8mm 307.7mm 311mm
TAIL WIDTH 289mm 294.1mm 295.8mm 297.5mm 299.3mm 302.2mm 301.5mm 304.8mm 307.7mm 311mm
EFFECTIVE EDGE 1152.5mm 1182.5mm 1202.5mm 1222.5mm 1242.5mm 1267.5mm 1220mm 1255mm 1280mm 1315mm
STANCE LOCATION 10 10 10 10 10 10 10 10 10 10
WEIGHT RANGE 110-160 lbs. / 50-73 kg. 120-170 lbs. / 54-77 kg. 125-175 lbs. / 57-79 kg. 130-180 lbs. / 59-82 kg. 145-195 lbs. / 66-88 kg. 150-200 lbs. / 68-91 kg. 130-180 lbs. / 59-82 kg. 150-200 lbs. / 68-91 kg. 155-205 lbs. / 70-93 kg. 175-210+ lbs. / 79-95 kg.
BINDING SIZES Medium Medium/Large Medium/Large Medium/Large Large Large Large Large Large Large


Burton Custom and Custom Wide Snowboard Specs 2011
Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard Custom Snowboard
BOARD SIZE 151cm 154cm 156cm 158cm 160cm 163cm 169Wcm 158Wcm 162Wcm 165Wcm
RUNNING LENGTH 1110mm 1140mm 1160mm 1180mm nullmm 1225mm 1275mm 1180mm 1215mm 1240mm
WAIST WIDTH 248mm 252mm 253mm 254mm nullmm 257mm 264mm 258mm 260mm 262mm
SIDECUT DEPTH 20.5mm 21.05mm 21.4mm 21.75mm nullmm 22.6mm 23.5mm 21.75mm 22.4mm 22.85mm
SIDECUT RADIUS 7.52m 7.73m 7.87m 8.01m nullm 8.31m 8.66m 8.01m 8.25m 8.42m
STANCE WIDTH 505mm 530mm 530mm 560mm nullmm 560mm 560mm 560mm 560mm 560mm
NOSE WIDTH 289mm 294.1mm 295.8mm 297.5mm nullmm 302.2mm 311mm 301.5mm 304.8mm 307.7mm
TAIL WIDTH 289mm 294.1mm 295.8mm 297.5mm nullmm 302.2mm 311mm 301.5mm 304.8mm 307.7mm
EFFECTIVE EDGE 1152.5mm 1182.5mm 1202.5mm 1222.5mm nullmm 1267.5mm 1315mm 1220mm 1255mm 1280mm
STANCE LOCATION 10 10 10 10 null 10 10 10 10 10
WEIGHT RANGE 110-160 lbs. / 50-72 kg. 120-170 lbs. / 55-80 kg. 125-175 lbs. / 59-81 kg. 130-180 lbs. / 68-91 kg. null 150-200 lbs. / 70-95 kg. 175-210+ lbs. / 80-95 kg. 130-180 lbs. / 59-81 kg. 150-200 lbs. / 68-91 kg. 155-205 lbs. / 70-92 kg.
BINDING SIZES Medium Medium/Large Medium/Large Medium/Large null Large Large Large Large Large


The Burton Custom 2010 Snowboard Specs
BOARD SIZE 144cm 148cm 151cm 154cm 156cm 158cm 162cm 166cm
RUNNING LENGTH 1050mm 1080mm 1110mm 1140mm 1160mm 1180mm 1215mm 1250mm
WAIST WIDTH 239mm 244mm 245mm 246mm 247mm 249mm 251mm 253mm
SIDECUT DEPTH 19.55mm 19.95mm 20.5mm 21.05mm 21.4mm 21.75mm 22.4mm 23.05mm
SIDECUT RADIUS 7.06mm 7.32mm 7.52mm 7.73mm 7.87mm 8.01mm 8.25mm 8.48mm
STANCE WIDTH 480mm 480mm 505mm 530mm 530mm 560mm 560mm 560mm
NOSE WIDTH 278.1mm 283.9mm 286mm 288.1mm 289.8mm 292.5mm 295.8mm 299.1mm
TAIL WIDTH 278.1mm 283.9mm 286mm 288.1mm 289.8mm 292.5mm 295.8mm 299.1mm
EFFECTIVE EDGE 1092.5mm 1122.5mm 1152.5mm 1182.5mm 1202.5mm 1222.5mm 1257.5mm 1295mm
STANCE LOCATION 10 10 10 10 10 10 10 10
WEIGHT RANGE 80-130 lbs. / 36-59 kg. 90-140 lbs. / 41-63 kg. 110-160 lbs. / 50-72 kg. 120-175 lbs. / 55-80 kg. 120-175 lbs. / 55-80 kg. 130-180 lbs. / 59-81 kg. 150-200 lbs. / 68-91 kg. 165-210 lbs. / 70-95 kg.
BINDING SIZES Small Small / Medium Small / Medium Small / Medium Medium Medium / Large Medium / Large Medium / Large
