2014 Burton Custom Flying V Twin Specs

Custom Flying V Snowboard

BOARD SIZE 151cm 154cm 156cm 158cm 160cm 163cm 158Wcm 162Wcm

RUNNING LENGTH 1100mm 1130mm 1150mm 1160mm 1180mm 1200mm 1150mm 1190mm

WAIST WIDTH 246mm 248mm 249mm 250mm 251mm 253mm 258mm 260mm

SIDECUT DEPTH 20.3mm 20.9mm 21.2mm 21.4mm 21.8mm 22.2mm 21.2mm 22mm

SIDECUT RADIUS 7.46m 7.66m 7.80m 7.86m 8.00m 8.14m 7.80m 8.07m

STANCE WIDTH 530mm 560mm 560mm 560mm 560mm 560mm 560mm 560mm

NOSE WIDTH 286.6mm 289.7mm 291.5mm 292.8mm 294.6mm 297.3mm 300.5mm 303.9mm

TAIL WIDTH 286.6mm 289.7mm 291.5mm 292.8mm 294.6mm 297.3mm 300.5mm 303.9mm

EFFECTIVE EDGE 1145mm 1175mm 1195mm 1205mm 1225mm 1250mm 1200mm 1240mm

STANCE LOCATION 0 0 0 0 0 0 0 0

WEIGHT RANGE 125-165 lbs. / 57-75 kg. 130-170 lbs. / 59-77 kg. 135-175 lbs. / 61-79 kg. 145-185 lbs. / 66-84 kg. 155-195 lbs. / 70-88 kg. 165-205 lbs.+ / 75-93 kg.+ 145-185 lbs. / 66-84 kg. 165-205 lbs.+ / 75-93 kg.+

BINDING SIZES Small/Medium Medium Medium/Large Medium/Large Medium/Large Medium/Large Large Large


BOARD SIZE	151cm	154cm	156cm	158cm	160cm	163cm	158Wcm	162Wcm
RUNNING LENGTH	1100mm	1130mm	1150mm	1160mm	1180mm	1200mm	1150mm	1190mm
WAIST WIDTH	246mm	248mm	249mm	250mm	251mm	253mm	258mm	260mm
SIDECUT DEPTH	20.3mm	20.9mm	21.2mm	21.4mm	21.8mm	22.2mm	21.2mm	22mm
SIDECUT RADIUS	7.46m	7.66m	7.80m	7.86m	8.00m	8.14m	7.80m	8.07m
STANCE WIDTH	530mm	560mm	560mm	560mm	560mm	560mm	560mm	560mm
NOSE WIDTH	286.6mm	289.7mm	291.5mm	292.8mm	294.6mm	297.3mm	300.5mm	303.9mm
TAIL WIDTH	286.6mm	289.7mm	291.5mm	292.8mm	294.6mm	297.3mm	300.5mm	303.9mm
EFFECTIVE EDGE	1145mm	1175mm	1195mm	1205mm	1225mm	1250mm	1200mm	1240mm
STANCE LOCATION	0	0	0	0	0	0	0	0
WEIGHT RANGE	125-165 lbs. / 57-75 kg.	130-170 lbs. / 59-77 kg.	135-175 lbs. / 61-79 kg.	145-185 lbs. / 66-84 kg.	155-195 lbs. / 70-88 kg.	165-205 lbs.+ / 75-93 kg.+	145-185 lbs. / 66-84 kg.	165-205 lbs.+ / 75-93 kg.+
BINDING SIZES	Small/Medium	Medium	Medium/Large	Medium/Large	Medium/Large	Medium/Large	Large	Large
